The Rout-R-Lift II has all the same great features as our Mast-R-Lift II but at a price we know you will appreciate. This lift is made out of aluminum with a phenolic top plate. The Rout-R-Lift II comes in 5 different styles depending on the router and router diameter you plan to use. Please verify which router you plan to use before purchasing one of these lifts.
Top Plate Dimensions: 9 1/4" × 11 3/4" x 3/8”
DOUBLE SEALED BALL BEARING CONSTRUCTION
We wanted our Rout-R-Lift II to be as smooth as our new Mast-R-Lift II while raising and lowering your lift. To achieve this, we decided to add a double sealed bearing to the spindle. This provides a lifetime of use and a Lift so smooth you can raise and lower your motor with one finger.
BEARING THE TENSION OF THE LIFT
The shafts on the Rout-R-Lift II, like all our Router Lifts, are pressed into a shaft mount with hydraulic pressure. We do not just thread our shafts to the top plate. The owner of JessEm spent many years as a Tool and Die maker before founding our company, and cutting corners was not an option. By pressing the shafts into a larger diameter mount we are able to attach the shafts to the top plate and fasten in place with more than one screw spreading the lateral load and providing a very rigid and durable mount that will withstand the toughest routing operations.
NO BENT WRENCHES
Like our current Mast-R-Lift II, bit changes above the table was a must for all routers that work with this lift without the need for bent wrenches.
All the machined components on the Rout-R-Lift II are machined on one of our CNC mills here in our Oro-Medonte, Ontario, Canada location.
WARNING - Cancer and reproductive harm. For more information please click: JessEm Prop65 Warnings or
3 - Insert Rings (1-3/8", 2" and 2-1/2")
1 - Insert Wrench
1 - Lift Adjustment Handle
10 - Stainless Steel Set Screws with Blue Nylok Patch
4 - Mounting Screws
02310 Rout-R-Lift II For Use With PC 690/890, DW 610/616/618, BOSCH 1617/1618, Craftsman 17540/17541/17542/17543(320-24604)/27680/28084/28190/320-27683 and some other 3.5" Motor Diameter.
02311 Rout-R-Lift II For Use With MAKITA 1101 (3.218" Motor Dia.)
02312 Rout-R-Lift II For Use With HITACHI M12VC-KM2VC (3.267" Motor Dia.)
02313 Rout-R-Lift II For Use With MILWAUKEE 5615/5616/5619 (3.32" Motor Dia.)
02314 Rout-R-Lift II For Use With RIGID 29302 (3.625" Motor Dia.)
